81
9 INTERNET SECURITY
DMS-CTC-20101206-0017 v1.0
9.2 Firewall
Introduction
The Technicolor Gateway comes with an integrated firewall that helps you protect your network from attacks from the
Internet. This firewall has a number of predefined levels to allow you to adjusted the firewall to your needs.
The Firewall is disabled by default. This means that all traffic passing through the Technicolor Gateway (from and to the
Internet) is allowed.
Predefined security levels
The Technicolor Gateway has a number of predefined security levels. The following levels are available:
BlockAll:
All traffic from and to the Internet is blocked. Game and Application Sharing is not allowed by the firewall.
Standard:
All outgoing connections are allowed. All incoming connections are blocked, except for inbound connections assigned to
a local host via Game and Application Sharing.
Disabled:
All in- and outgoing traffic is allowed to pass through your Technicolor Gateway, including Game and Application
Sharing.
This is the default firewall level.
Changing the security level
Proceed as follows:
1 Browse to the Technicolor Gateway GUI.
2 On the Toolbox menu, click Firewall.
3 The Firewall page appears. In the upper-right corner, click Configure.
4 Under Security Settings, select the security level of your choice and click Apply.
Creating your own security level
Proceed as follows:
1 In the Toolbox menu click Firewall.
2 In the Firewall section, go to the Configure page.
3 In the Pick a task list, click Create a new Security Level.
4 In the Name box, type a name for the new security level and select an existing security level to clone from.
5Click Apply.
6 A page with the firewall settings of your newly created security level appears. Click Edit.
7 Enter the following information:
The Name of the firewall rule.
Although BlockAll will block all connections, some mandatory types of traffic such as DNS will still be relayed
between LAN and WAN by the Technicolor Gateway.
Once you create a security level, you can not delete it anymore. It will always available in the list of available security
levels.
