Before use Getting started
English
(11)
11
Putting the player together
Anti-skating
control
(
17)
1
Attach a cartridge (store-bought)
tentatively.
Follow the cartridge’s instructions to
correctly attach it to the head shell, and
tighten the screws lightly.
z
If the mounting screws are included in
the cartridge, use them.
z
When playing SP records, use a cartridge
for SP records.
z
Use a commercially available mini flat
screwdriver (4 mm
[
5
/
32
”
]
).
Attaching the cartridge
Fit the overhang gauge to the head shell.
l
Tighten the screw for cartridge.
The overhang can be adjusted optimally.
Screw for
cartridge
Overhang gauge
Head
shell
Head shell
Lead wire
Cartridge
Stylus
(Lead wire) (Terminal)
Red
R+ (Red)
Green
R- (Green)
White
L+ (White)
Blue
L- (Blue)
Screw for cartridge
Terminal
(Example)
52 mm
2
Adjust the overhang.
Use the included overhang gauge.
k
Move the cartridge to line the stylus tip up
with the end of the gauge.
z
The cartridge should be parallel on
the shell head when viewed from the
top and side (the illustration is the top
view).
z
Be careful not to allow the cartridge to
slip out of place.
Stylus tip
(2-3/64“)
Nuts
Washers
