BASIC OSCILLOSCOPE DISPLAYS
PRELIMINARY
The procedures in this section will allow you to set up
and operate your instrument to obtain the most commonly
used basic oscilloscope displays. Before proceeding with
these instructions, verify that the Line Voltage Selector
switch and
the Regulating Range Selector bar are placed in
the proper positions and that the correct fuse is installed
for
the line voltage being used. Refer to the Operating
Safety section of this manual for the information and pro-
cedures relating
to line voltage, regulating range, and fuse
selection. Verify
that the POWER switch is off (push
button pressed in) before plugging the power cord into the
line voltage socket.
@
