Time Duration Using DM44
Obtain a Delayed Sweep Display, with controls set as
follows:
DM44 FUNCTION
HORIZ DISPLAY
B (DLY'D) TRIGGER
SOURCE
VAR TIME/DIV
A TIME/DIV
B TIME/DIV
DM44 /::,.TIME
TIME
ALT
STARTS AFTER DELAY
Calibrated detent position
Set
to display a single
event
Three or
four positions
more clockwise than A
TIME/DIV setting
To move the time
measurement point to the
right
of the reference
point
1. Using the DELAY TIME POSITION control, move
the reference point to a convenient horizontal
graticule line
(see Figure 30, Point A).
2. Using the /::,. TIME control, move the time-
measurement point along the
same horizontal
graticule line
to the beginning of the next waveform
cycle
(see Figure 30, Point B).
68 465B/DM44 Operators
0
--.....
I~T!NS~FI!D
I ~
~~ES
1\
I
.l.
I-, 1
_.
'
:-
~
(&\ lJ
I
~
,
If
\
_j
)_
~
lL
,.,
I"'
(AI A SWEEP DISPLAY
(BI B DL Y'D DISPLAY
Figure 30. Time duration and frequency.
2039-31
@
I
I
a·
I
I
1
I
I
I
