SINGLE SWEEP DISPLAY
1. Preset instrument controls and obtain a Normal
Sweep Display. For random signals, set the trigger
circuit
to trigger on a signal that is approximately the
same amplitude and frequency as the random signal.
2. Press
the SINGL SWP push button on the A TRIG
MODE switch. The
next trigger pulse starts the sweep
and displays a single trace.
If no triggers are present,
the READY indicator should illuminate, indicating
that the A Sweep generator circuit is set and waiting
for a trigger.
3. When
the sweep is complete, the circuit is "locked
out", and the READY indicator turns off.
4. Press the SINGL SWP push button again to prepare
the circuit for another Single Sweep Display.
465B/DM44 Operators
25
