Instrument interface, front panel, and rear panel
Level meter. Am
plitude level is displayed. The following figure describes the
level meter.
1. Shows maximum
amplitude level of your
instrument.
2. Shows the range of high
limit and low limit set by
the u ser.
3. Shows the amplitude level
that is currently selected.
View button
The instru
ment provides the following three screen view formats:
Waveform parameter and graph display
Graph comparison
Waveform parameter comparison
AFG3000 and AFG3000C Series User Manual 27
