Connectors
The arbitrary waveform generator has both output and input connectors. Do not apply external voltage to any output connector
and ensure proper restrictions are met for any input connector.
CAUTION. Always turn off the signal outputs when you connect or disconnect cables to/from the signal output connectors. If you
connect a (Device Under Test) DUT while the instrument signal outputs are in the On state, it may cause damage to the
instrument or to the DUT.
External device connections
For many applications, powered external devices may need to be used on the output of the AWG. These may include Bias-Ts,
Amplifiers, transformers etc. It is important to guarantee that these components are adaptable for the specific AWG and that they
are configured as required by the device manufacturer.
NOTE. The term Device means external powered devices such as bias-t, whereas Device Under Test (DUT) refers to the circuit
being tested.
It is critical that there is minimal inductive kickback into the AWG output when the device is connected or disconnected. Inductive
kickback can occur if the external device can hold a charge and then discharge when a ground path becomes available such a
connection to the output termination of the AWG channel output. To minimize this inductive kickback care should be taken before
connecting the device to the AWG output.
Some simple guidelines to follow for device connection are:
1. Always use a grounded wrist strap when connecting cables.
2. Make sure the power supply to the device is turned off or unplugged.
3. Establish ground connection between the device and AWG test system.
4. Make sure the DUT's power supply is turned off or set at 0 volts.
5. Discharge cables to ground before connecting to the AWG.
6. Engage connector between device and AWG output.
7. Power up device power supply.
8. Set device voltage power supply (bias level voltage for bias-t) to desired voltage.
9. Power up DUT power supply.
Enhancements for your instrument
Upgrades and plug-ins purchased with your instrument are pre-installed. You can view these by going to Utilities > About my
AWG. If you purchase an upgrade or plug-in after you've received your instrument, you may need to install a license key to
activate the feature. Use the Install Licenses dialog box to enable the upgrades that you purchased from Tektronix for your
instrument. For the most current list of upgrades, go to www.tektronix.com or contact your local Tektronix representative.
Your instrument can be enhanced by several different methods:
■
Software enhancements: Enhancements ordered at the time of your purchase are pre-installed. These can also be
purchased post sales and may require the installation of software in addition to installing a license to activate.
■
Hardware enhancements: Features that require/enable hardware on the instrument. These can be ordered with the
purchase of the instrument or as a post-purchase addition.
■
Plug-ins: Applications that enhance a host application. Plug-ins designed to operate with an AWG5200 series instrument are
also able to operate with the SourceXpress Waveform Creation software. Plug-ins with a floating license can be moved
between instruments or SourceXpress.
Install the instrument
AWG5200 Series Installation and Safety Instructions 13
