Preface
Optional Acces
sories
Accessory Description Tektronix par
tnumber
DPO2EMBD
The embedded serial triggering and analysis module
enables trigg
ering on packet level information on I
2
C and
SPI serial buses, as w ell as bus views, bus decoding,
search tools, and packet decode tables with timestamp
information
DPO2EMBD
DPO2AUTO
The automotive serial triggering and analysis module
enables trig
gering on packet level information on CAN
and LIN serial buses, as well as bus views, bus decoding,
search tools, and packet decode tables with timestamp
informatio
n
DPO2AUTO
DPO2COMP
The computer triggering and analysis module enables
triggerin
g on RS-232, RS-422, RS-485 and UA RT serial
buses, search tools, bus views, bus decoding in hex,
binary, and ASCII, and decode tables with timestamp
informati
on
DPO2COMP
DPO2CONN The conne
ctivity module adds an Ethernet port for
remote programmability an d a Video Out port to display
the oscilloscope screen on an external monitor
DPO2CONN
NEX-HD2HEADER
Adapter that routes the channels from a Mictor connector
to 0.1 in
ch header pins
NEX-HD2HEA DER
TekVPI probes that work with
MSO/DP
O2000B Series oscilloscopes
Note: These probes require the use
of the TekV PI external power adapter
listed
below.
Visit t
he Oscilloscope Probe and Accessory Selector
Tool on the Tektronix website at www.tektronix.com
TekVPI external power adapter
Suppl
ies external power to a TekVPI probe
119‑7465‑XX
TPA-B
NC
Note: This adapter requires the use
of the TekV PI external power adapter
list
ed above.
TekVP
I to TekProbe II BNC Adapter
TPA-B
NC
Deskew pulse generator Deskew pulse generator and signal source with TekVPI
osc
illoscope interface
TEK
-DPG
Power measurement deskew and
cal
ibration fixture
Con
verts TEK-DP G pulse generator output into a series
of test point connections
067-1686-00
TEK-USB-488 Adapter GPIB to USB Adapter TEK-USB-488
Ra
ckmount kit
Ad
ds rackmount brackets
RM
D2000
S
oft transit case
C
ase for carrying an oscilloscope
A
CD2000
Hard transit case
T
raveling hard case, which requires use of the soft transit
case (ACD2000)
H
CTEK4321
DPO2000B and MSO2000B Series
Oscilloscopes Service manual
Service information on DPO2000B and MSO2000B series
oscilloscopes
077-0737‑XX
DPO2000B and MSO2000B Series
Oscilloscopes Application Module
Installation
Describes how to install application m odules in
DPO2000B and MSO2000B series oscilloscopes
071-2330‑XX
MSO2000B and DPO2000B Installation and Safety Instructions 3
