Tektronix DPO70000C/DX Series Service Manual

Replaceable Parts (DPO7000 Series)
Table 5-5: Repl
aceable parts – Power interface and Acquisition assemblies (DPO7000 Series)
Fig. & index
number
Tektronix
part
number
Serial no.
effective
Serial no.
discont’d Qty Name & descript
ion
5-6
POWER INTERFA
CE AND ACQUISITION ASSEMBLIES
-1 211-1050-00 19
SCREW, MACHINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15
-2 174-5048-00 1
CA ASSY; USB 1.0
-3 174-5159-00 1
CABLE ASSY; G
PIB
-4 335-1518-00 1
LABEL, T EKLINK, SAFETY CONTROLLED
-5
211-1206-0
0
2
SCREW, JACK; 2-56 ID X 4-40 OD,.188 HEX, SS
-6 671-5912-02 1
CIRCUIT BD
ASSY; POW ER INTERFACE, 6795912XX, TESTED;
WIRED, 389352600
-7
213-1061-00 2
JACKSCREW
; 6-32 X 0.320 EXT THD, M3.5 X 0.6-6 INT THD X 0.215L,
GPIB, BLACK OXIDE, BULK PACK
-8 211-0747-00 3
SCREW, MA
CHINE; 6-32 X 0.188, PNH, STL, CDPL, T-15 TORX DR
672-5819-54 1
CIRCUIT BD ASSY; ACQ,6725819XX, TESTED; WIRED, (DPO7254
ONLY)
672-6166-54 1
CIRCUIT BD ASSY; ACQ, 6726166XX, TESTED; WIRED, (DPO7104,
DPO7054
ONLY)
-9
672-6172-50 1
CIRCUIT BD ASSY; ACQ, 6726172XX, TESTED; W IRED, (DPO7354
ONLY)
-10 441-2436-00 1
CHASSIS; ACQ; AL, SAFETY CONTROLLED
-11 174-51
61-00
1
CABLE ASSY; DISPLAY ADAPTER TO PCI BOARD
5–12 MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
