Tektronix DPO70000C/DX Series Service Manual

Replaceable Parts (DSA/DPO70000B Series)
Table 5-8: Repl
aceable parts – External 2 (DSA/DPO70000B Series)
Fig. &
index
number
Tektronix
part
number
Serial no.
effective
Serial no.
discont’d Qty Name & description
5-9
EXTERNAL PARTS
-1 174-5226-00 1
CABLE ASSY; LINE FILTER
-2 211-1050-00 16
SCREW, MACHINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15
200-4936-00 1
COVER; EMI BOTTOM, DPO/DSA70804/70604/70404
200-5007-00 1
COVER; EMI BOTTOM, DPO/DSA720004/71604/71254
-3
200-5007-00 1
COVER; EMI BOTTOM, DPO/DSA7
-4 200-5067-00 1
COVER, BOTTOM; COSMETIC; W/FEET
-5
212-0232-00 2
SCREW,MACHINE; 8-32 X 1.125L, PNH, STL, BLACK ZINC SPEC
#ASTM B633 TYPE II, T-20
367-0528-00 1
HANDLE, CARRYING; DUAL DUROMETER MOLDED,
POLYPROPYLENE, VINYL GRIP SECTION
-6
407-4887-00 1
BRACKET; HANDLE BASE, PC/ABS ALLOY, BAYER BAYBLEND FR-110,
TEK BLUE
-7
348-1515-00 1
FEET, CABINET; BLACK, GLASS-FIBRE REINFORCED PLASTIC, SET
OF 4 FEET, 4 RUBBER INSERTS
-8 211-1224-00 4
SCREW, MACHINE, BLACK
-9 348-1817-00 2
FOOT, SKID
5–18 MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
