Tektronix DPO70000C/DX Series Service Manual

Replaceable Parts (DSA/DPO70000B Series)
Table 5-10: Rep
laceable parts – Power supply and fans (DSA/DPO70000B Series)
Fig. &
index
number
Tektronix
part
number
Serial no.
effective
Serial no.
discont’d Qty Name & description
5-11
POWER SUPPLY AND FANS
119-6982-xx 1
POWER SUPPLY: AC-DC; 1200W, +48V 25A, +12V 1A, 85-264VAC,
47-63HZ, ELCON 377-0002-00100A, IEC320-C22; 11.5X6.75X2.75IN;
CLOSED CHASSIS
-1
407-5381-00 B110100
BRACKET;POWER SUPPLY
-2 211-1050-00 12
SCREW, MACHINE; 6-32X0.312 L, PNH, STL CAD PLT, T15
-3 436-0422-00 1
TRAY, FAN; CHASSIS ASSY, W/6 FANS MOUNTED; HAMMERHEAD
441-2563-00 1
CHASSIS ASSEMBLY, MAIN, ADVANTECH AIMB-562 UATX, SAFETY
CONTROLLED;DPO70000B SERIES
-4
407-5366-00 1
BRACKET, IO BACK PANEL PLATE, DPO/DSA7000B SERIES
-5
335-1634-00 1
LABEL, CHASSIS, REAR COSMETIC
-6 335-0263-01 1
MARKER, IDENT; SUPER LABEL, BLANK ROLL STOCK
-7
335-0347-00 1 MARKER,IDENT; REAR PANEL, BLANK, 2.100 X 2.700
-8 065-0759-01 B010100 B110099 1
CIRCUIT BOARD; POWER DISTRIBUTION, DSA70000, DPO70000
-8a 671-6385-00 B110100 1
CIRCUIT BOARD; POWER DISTRIBUTION, DSA70000B, DPO70000B
-9 343-1585-00 1
CLAMP; WIRE ROUTING CLAMP, FLAT CABLE BLIND HOLE
MOUNTED, NYLON
-10 335-1604-00 1
LABEL, REAR I/O PLATE, LEXAN
