Clear and sanitize procedures
NOTE. Sanitizing or clearing the instrument cannot be reversed. But the
instrument application software and calibration information is left unchanged
after the sanitizing or clearing operations. There is no need for a post-
sanitization or clear procedure for the MDO3000 Series of instruments. The
instrument can begin normal use and function immediately after the sanitizing or
clearing procedures.
Disable the USB device port
Complete the following steps to disable the USB device.
1. Remove any USB cable or device from the USB device port on the rear of
the instrument.
2. Push the front-panel Utility button.
3. Push the Utility Page lower-bezel button and use the Multipurpose a knob
to select I/O.
4. Push the USB lower-bezel button.
5. Push the Disabled (Off Bus) side-bezel button to disable the USB device
port.
The USB device port is now disabled and no longer allows traffic in or out of the
port.
Use the MDO3SEC option to disable all I/O ports
If your instrument has the MDO3SEC option installed, use the following
procedure to turn off all of the I/O ports.
1. Push the front-panel Utility button.
2. Push the Utility Page lower-bezel button and use the Multipurpose a knob
to select Security.
3. Push the Security Password lower-bezel button.
4. Use the Multipurpose knob to enter a password.
5. Push the I/O Ports lower-bezel button.
To disable all USB and Ethernet ports on the oscilloscope, push the OK
Disable All Ports on the side-bezel button.
6. Push the Menu Off front-panel button to close the dialog box.
7. Power off the oscilloscope, and then power it back on to complete the
process.
MDO3000 Series Declassification and Security Instructions 7
