Tektronix MSO5054 User Manual

Install Your Ins
trument
Install Your Instrument
Unpack the instrument and check that you received all items listed a s Standard Accessories. Recommended accessories,
probes, instrument options, and upgrades are listed in the online help. Check the Tektronix Web site (www.tektronix.com)
for the most current information.
Standard Accessories
Accessory Tektronix part number
MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, and
DPO5000 Series Digital Phosphor Oscilloscopes User Manual
071-2790-xx
Product Software DVD, MSO70000/C, DSA70000B/C, DPO70000B/C, and
DPO7000 series
020-3026-xx
Operating System Restore DVD, MSO70000/C, DSA 70000B/C,
DPO70000B/C, and DPO7000 Series
020-3019-xx
Online Help (part of the product software)
—
Performance Verification (on the documentation browser)
077-0063-xx
Programmer Online Guide (on the documentation browser)
077-0010-xx
NIST, Z540-1, and ISO 9000 Calibration Certificate
—
One TekConnect adapter, ≥4 GHz models only TCA-BNC
Four TekConnect adapters, ≥4 GHz models only TCA-292MM
One 16-channel digital probe with accessory kit, MSO5000 models only
P6616
One passive probe per channel, M SO5204, MSO5104, DPO5204, and
DPO5104
TPP1000
One passive probe per channel, M SO5054, MSO5034, DPO5054, and
DPO5034
TPP0500
Touchscreen stylus, MSO 5000 and DPO5000
119-6107-xx
NI SignalExpress software, MSO5000 and D PO5000
063-3967-xx
Keyboard, ≥4 GHz models only
119-7083-xx
Mouse, optical 119-7054-xx
Front Cover, MSO5000 and DP O5000
All other models
200-5052-xx
200-4963-xx
Wrist Strap, ≥4 GHz models only
006-3415-05
Accessory Pouch
≥4GHzmodels
DPO7000 models
MSO5000 and DPO5000 models
016-1441-xx
016-1966-xx
016-2029-xx
Nero OEM Software CD, ≥4 GHz and DPO7000 models
063-3781-xx
MSO70000/C, DPO/DSA70000B/C, DPO7000, and MSO/DP O5000 Series U ser M anual 1
