TM 11-6625-2980-14
SPECIFICATIONS
Power Requirements
Line Voltage Ranges. Universal Transformer: 100,
110, 20, 200, 220, 240 VAC, all within 10%. Range
changing or transformer accomplished with quick-
change line-selector block
Line Frequency Ranges. Universal Transformer:
48 Hz to 440 Hz.
Power Consumption. Maximum primary power
approximately 120 W at high line. Actual power
consumption depends on plug-in selection and operating
modes.
Power Cord Conductor Identification
Conductor Color Alternate
Color Color
Ungrounded (Line) Brown Black
Grounded (Neutral) Blue White
Grounding (Earthing) Green-Yellow Green-Yellow
Supplies (Unregulated)
Two 25 VAC windings, 500 mA each, supplied to
each compartment, independently.
+33.5 V and -33.5 V, 1 A maximum each supply,
shared by all compartments.
17.5 VAC and +11.5 V, 3.6 A maximum, shared in
any combination between these two supplies and shared
among all compartments
NOTE
Current and voltage ratings are for main frame
maintenance only. In practice, not all available power
may be used at once.
Temperature Range
Operating: 0°C to +50°C. Nonoperating: -40°C to
+75°C.
Altitude Range
Operating: To 15,000 feet. Nonoperating: To 50,000
feet.
Other
Dimensions with Feet and Bail: H 6.0 in., W 8.7 in.,
L
15.3 in.
Weight without Plug-ins: Approximately 9.5 lb.
A-6
