Accessories
Accessories
All accessories (standard and optional) are available by contacting your local
Tektronix field office.
Standard Accessories
TPP0101 or TPP0201, 10X Passive Voltage Probe. The TPP0101 probes have
a system bandwidth of DC to 100 MHz at -3 dB and ship standard with TBS1000
oscilloscope models that have bandwidths up to 100 MHz.
The TP P0201 probes have a system bandwidth of DC to 200 MHz at -3 dB and ship
standard with TBS1000 oscilloscopes models that have bandwidths of greater than
100 MHz.
TBS1000 Series O scillosco pe Installation and Safety Manu al. A single printed
manual is included (071-3099-XX). Refer to the Optional Accessories for a list of
electronically available manuals.
Customer
Documentation Browser CD-ROM. This CD offers additional product
information (063-4479-XX).
Optional Accessories
P6101B 1X Passive Voltage Probe. The P6101B probe has a 15 MHz bandwidth
witharatingof300V
RMS
CAT II.
RM2000B Rackm ount Kit. The RM2000B Rackmount Kit lets you install a
TBS1000 series oscilloscope into an industry-standard 19 inch rack. The rackmount kit
requires seven inches (18 cm) of vertical rack space. You can turn the oscilloscope
power on or off from the front of the rackmount kit. The rackmount kit does not have
slide-out capability.
36 TBS1000 Series Oscilloscopes Installation and Safety Manual
