Tektronix TBS1000 Series User Manual

Adjustment Procedures
Table 5-2: Adjustment steps (cont.)
90
Sinewave Generator, 50 Ω
5kHz,1V
p-p
91
Sinewave Generator, 50 Ω
1 MHz, 100 mV
p-p
92
Sinewave Generator, 50 Ω
1MHz,1V
p-p
93
Sinewave Generator, 50 Ω
50 kHz, 1 V
p-p
94
Sinewave Generator, 50 Ω
20 MHz, 1 V
p-p
95
Sinewave Generator, 50 Ω
BWL, 25 mV
p-p
96
Sinewave Generator, 50 Ω
BWL, 50 mV
p-p
97
Sinewave Generator, 50 Ω
BWL, 100 mV
p-p
98
Sinewave Generator, 50 Ω
BWL, 250 mV
p-p
99
Sinewave Generator, 50 Ω
BWL, 500 mV
p-p
100
Sinewave Generator, 50 Ω
BWL, 1 V
p-p
101
Sinewave Generator, 50 Ω
5kHz,2.5V
p-p
102
Sinewave Generator, 50 Ω
1MHz,2.5V
p-p
103
Sinewave Generator, 50 Ω
50 kHz, 2.5 V
p-p
104
Sinewave Generator, 50 Ω
20 MHz, 2.5 V
p-p
105
Sinewave Generator, 50 Ω
BWL, 2.5 V
p-p
Ch 4
(4-ch models
only)
Sinewave
generator
106
Sinewave Generator, 50 Ω
BWL, 5 V
p-p
NOTE. BWL=full bandwidth for the TBS1022, 1042, 1062, 1102, and 1104.
BWL=180 Mhz for the TBS1152 and TBS1154
5–8 TBS1000 Series O scilloscope Service Manual

Tektronix TBS1000 Series Specifications

General

Channels	2
Input Coupling	AC, DC, GND
Operating Temperature	0 °C to +50 °C
Memory Depth/Record Length	2.5 kpoints
Vertical Resolution	8-bit
Trigger Modes/Types	Edge, Pulse Width, Video
Interfaces	USB 2.0
Math Functions	+, -, *, /
Probe Interface	BNC
Bandwidth	50 MHz to 200 MHz
Display	7-inch WVGA (800x480) LCD
Maximum Input Voltage	300 VRMS, CAT II
