TDS 620A, 640A, & 644A User Manual
2Ć3
At a Glance
The
At a Glance
section contains illustrations of the display, the front and rear
panels, and the menu system. These will help you understand and operate
the digitizing oscilloscope. This section also contains a visual guide to using
the menu system.
ON/STBY Switch,
page 1-3
CLEAR MENU
Removes Menus
from the Display
Main Menu Buttons,
page 2-7
Side Menu
Buttons,
page 2-7
File System,
page 3-55
(Optional on
TDS 640A &
TDS 620A)
Front Panel Map —
Left Side
To Next Page
