TDS1000B and TDS2000B Series Oscilloscope Service Manual
1-1
Specifications
These specifications apply to all TDS1000B and TDS2000B series oscilloscopes.
To verify that an oscilloscope meets specifications, it must first meet the
following conditions:
H The oscilloscope must have been operating continuously for twenty minutes
within the specified operating temperature.
H You must perform the Do Self Cal operation, accessible through the Utility
menu, if the operating temperature has changed by more than 5 °C(9°F)
since the last time the Do Self Cal operation was performed.
H The oscilloscope must be within the factory calibration interval of one year.
Specifications begin in Table 1--1. All specifications are guaranteed unless noted
“typical.” Specifications that are marked with the n symbol are checked in the
chapter Performance Verification.
Table 1- 1: Oscilloscope specifications
Acquisition
Acquisition Modes Sample, Peak Detect, and Average
Acquisition Rate,
typical
Up to 180 waveforms per second, per channel (Sample acquisition mode, no measurements)
Single Sequence Acquisition Mode Acquisition Stops After
Sample, Peak Detect Single acquisition, all channels simultaneously
Average N acquisitions, all channels simultaneously. N is selectable from 4,
16, 64, and 128
