Telcoma Automations T224 User Manual

GB
38
INSTRUCTIONS FOR INSTALLATION AND PROGRAMMING
FEATURES
TECHNICAL DATA
- This handbook is aimed at qualified technical installation personnel
- Carefullyread all instructions in this handbook before installation.
- Improperuse of the product or incorrect connections could impair correctoperation of the unit and safety of the final user.
This control unit is designed for the automation of:
- two-leaf gates with or without limit switches
- single leaf gates with or without limit switches
- double leaf sliding gates with limit switches
- single leaf sliding gates with limit switches
The control unit is equipped with:
- encoder and/or current sensitivity motor control
- programmable motor deceleration
- soft start
- photocell operation check (Photo Test)
- self-diagnostics of motor drives (MOSFET)
- connectors for OC receivers and/or BOARD receivers
Power supply Vac 230 ±10%
Frequency Hz 50/60
Absorption on stand-by (230V) mA 18 / 25 min / max
Maximum absorption (230V) A 2
Max. motor output 24V VA 360 (2X180)
operating temperature °C -20 +60
Box dimensions (L xHxD) mm 220x280x120
Electrical parameters U.M. T224
