Tenda AC5 User Manual

120
System Settings
11
This module includes LAN Settings, DHCP Reservation, WAN Settings, Time Settings, Login Password, Reboot
and Reset, Firmware Upgrade, Backup/Restore, Remote Management, System Status, System Log, and Automatic
Maintenance.
11.1 LAN Settings
11.1.1 Overview
This module enables you to do the followings:
 Modify the LAN IP address of the router.
The LAN IP address is the management IP address of the router, which is 192.168.0.1 by default and
can be modified if necessary.
 Modify parameters of the DHCP server.
If the DHCP Server is enabled, the DHCP server can automatically assign IP address, subnet mask,
gateway and so on to the clients connected to the router. If this function is disabled, you have to
manually configure the IP address of your client to access the internet. You are recommended to retain
the DHCP server enabled.
 Configure the DNS settings assigned to the client.
To access the configuration page, choose System Settings > LAN Settings.

Tenda AC5 Specifications

General

Antennas quantity	4
Antenna gain level (max)	5 dBi
Certification	CE/FCC/RoHS
Built-in processor	Yes
Processor frequency	1000 MHz
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1167 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
VPN support	L2TP/PPTP/IPSec
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
SIM card slot	No
Ethernet LAN (RJ-45) ports	3
Output current	1 A
Output voltage	9 V
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN, WLAN
Security algorithms	WPA-PSK, WPA2-PSK, WPS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Harmonized System (HS) code	85176990
