Tenda AC5 User Manual

125
Parameter
Description
later under the circumstance that the quality Ethernet cable has been connected
correctly. You can select 10 Mbps FDX or 10 Mbps HDX from the drop-down list
box of Speed.
Otherwise, you are recommended to retain the default configuration
Auto-negotiation.
MAC Address
It is used to clone the MAC address accessible to the internet to the WAN port of
the router. If the router cannot access the internet after you configure the
internet settings, it is perhaps that the ISP has bound the connection information
with a MAC address. In this case, you can try to clone the MAC address, and try to
access the internet again.
 Default: It is used to restore the MAC address of the WAN port of the
router to factory settings.
 Clone local MAC address: It is used to set the MAC address of the WAN
port to the MAC address of the current device managing the router.
 Set MAC address: It is used to set the MAC address of the WAN port
manually.
11.3.2 Modifying MTU Value
You are recommended to retain the default value of MTU, unless the following cases happen:
 Websites, for example secure websites (PayPal login page) are inaccessible.
 Email service fails, or FTP, POP and other servers are inaccessible.
In these cases, you can try to decrease the MTU value from the maximum value 1500 (recommended range:
1400-1500).
MTU
Description
1500
It is commonly used for non-PPPoE and non-VPN dial-up connections.
1492
It is used for PPPoE dial-up connections.
1472
It is the maximum value for the ping command. (A packet with a larger size is
splitted.)
1468
It is used for DHCP connections.
1436
It is used for VPN or PPTP connections.
11.3.3 Changing the MAC Address of the WAN Port
Ensure that the MAC address to be cloned is correct! The MAC address of the computer that can access
the internet properly or the MAC address of the WAN port of the router that can access the internet
properly is the correct one.
1. To access the configuration page, choose System Settings > WAN Settings.

Tenda AC5 Specifications

General

Antennas quantity	4
Antenna gain level (max)	5 dBi
Certification	CE/FCC/RoHS
Built-in processor	Yes
Processor frequency	1000 MHz
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1167 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
VPN support	L2TP/PPTP/IPSec
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
SIM card slot	No
Ethernet LAN (RJ-45) ports	3
Output current	1 A
Output voltage	9 V
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN, WLAN
Security algorithms	WPA-PSK, WPA2-PSK, WPS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Harmonized System (HS) code	85176990
