Tenda AC5 User Manual

45
Parameter descriptions
Parameter
Description
2.4 GHz/5 GHz
Network
It specifies whether to enable the 2.4 GHz/5 GHz network.
WiFi Name
It specifies the names of 2.4 GHz and 5 GHz network. You can change them if needed.
After the router accesses the internet, wireless clients like smart phones can access the
internet using these wireless names.
Encryption
Mode
This router supports the following encryption modes:
 None: It indicates that wireless network is not encrypted and any clients can
access the network. This option is not recommended as it leads to low
network security.
 WPA-PSK: It indicates that WPA-PSK/AES is adopted to authenticate users.
 WPA2-PSK: It indicates that WPA2-PSK/AES is adopted to authenticate users.
 WPA/WPA2-PSK (recommended): It indicates that both WPA-PSK/AES and
WPA2-PSK/AES are adopted to authenticate users.
WiFi Password
It specifies the password required when a client accesses the wireless network of the
router.
Hide
It specifies whether to prevent a WiFi name from being detected by wireless devices. If
this function is enabled, the corresponding WiFi signal is not broadcast. Therefore, the
name is not displayed on available wireless networks list of a wireless device. To
connect a wireless device such as a smart phone to the WiFi network, you need to
manually enter the WiFi name of the network on the device.
6.1.2 Modifying WiFi Name and Password
Assume that you modify the WiFi name and password of 2.4 GHz network to Tenda_2.4G and 123456789, WiFi
name and password of 5 GHz network to Tenda_5G and 987654321.
Procedures:
Step 1 Click WiFi Settings > WiFi Name & Password.
Step 2 Modify 2.4 GHz WiFi network information.
(1) WiFi Name: Enter Tenda_2.4G.
(2) Encryption Mode: You can configure it manually based on your requirement. Assume that the
mode in this example is WPA/WPA2-PSK (recommended).
(3) WiFi Password: Enter 123456789.
Step 3 Modify 5 GHz network WiFi information.
(1) WiFi Name: Enter Tenda_5G.
(2) Encryption Mode: You can configure it manually based on your requirement. Assume that the
mode in this example is WPA/WPA2-PSK (recommended).
(3) WiFi Password: Enter 987654321.

Tenda AC5 Specifications

General

Antennas quantity	4
Antenna gain level (max)	5 dBi
Certification	CE/FCC/RoHS
Built-in processor	Yes
Processor frequency	1000 MHz
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1167 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
VPN support	L2TP/PPTP/IPSec
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
SIM card slot	No
Ethernet LAN (RJ-45) ports	3
Output current	1 A
Output voltage	9 V
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN, WLAN
Security algorithms	WPA-PSK, WPA2-PSK, WPS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Harmonized System (HS) code	85176990
