Tenda AC5 User Manual

75
Parameter descriptions
Parameter
Description
Device Name
It specifies name of the device you want to apply the rule to.
MAC Address
It specifies MAC Address of the device you want to apply the rule to.
Internet Accessible
At
It specifies specific time for devices to access the internet through the router.
In
It specifies dates for devices to access the internet.
Website Access
Limit
It specifies whether to enable the website access limit function. By default, this
function is enabled.
Access Control
Mode
It specifies modes for website access limit in parental control rules.
 Blacklist: Only this device is banned to visit the websites listed in the
rules.
 Whitelist: This device is only allowed to visit the websites listed in the
rules.
Blocked/Unblocked
Websites
It specifies the websites that devices are banned/ allowed to visit in Internet
Accessible At.
8.3 Example
Application Scenario
Michael bought an AC5 for network, but his children always visited websites on the phone connected to the
router. For the good of his children’s learning, he intends to allow his children to access Google during 8:00-22:00
from Monday to Friday.
Solution
The Parental Control function of AC5 can address this requirement.
Procedures:
1. Click Parental Control.
2. In device list, locate the device you want to apply the rules to and click .

Tenda AC5 Specifications

General

Antennas quantity	4
Antenna gain level (max)	5 dBi
Certification	CE/FCC/RoHS
Built-in processor	Yes
Processor frequency	1000 MHz
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1167 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
VPN support	L2TP/PPTP/IPSec
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
SIM card slot	No
Ethernet LAN (RJ-45) ports	3
Output current	1 A
Output voltage	9 V
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN, WLAN
Security algorithms	WPA-PSK, WPA2-PSK, WPS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Harmonized System (HS) code	85176990
