CSR-20 & CSR-40, September 1999
1 Specifications
Return air to 460/230V, 3 Phase, 60 Hz Power 380/190V, 3 Phase, 50 Hz Power
evaporator Net Cooling Capacity Power Consp Net Cooling Capacity Power Consp
coil inlet Watts Kcal/hr BTU/hr kW @460V Watts Kcal/hr BTU/hr kW @380V
21.1 C (70 F) 13,770 11,840 46,990 11.0 11,470 9,865 39,145 9.2
1.7 C (35 F) 9,960 8,565 33,990 9.1 8,295 7,135 28,315 7.6
-17.8 C (0 F) 5,860 5,040 19,995 6.1 4,880 4,195 16,655 5.1
-28.9 C (-20 F) 3,810 3,275 12,995 5.0 3,170 2,728 10,825 4.2
CSR-40 Models with Three Evaporator Fans — Air Cooled Condensing*
*System net cooling capacity with a 37.8 C (100 F) ambient air temperature and R-404A.
Return air to 460/230V, 3 Phase, 60 Hz Power 380/190V, 3 Phase, 50 Hz Power
evaporator Net Cooling Capacity Power Consp Net Cooling Capacity Power Consp
coil inlet Watts Kcal/hr BTU/hr kW @460V Watts Kcal/hr BTU/hr kW @380V
21.1 C (70 F) 12,660 10,890 43,200 10.8 10,545 9,070 35,985 9.0
1.7 C (35 F) 9,100 7,825 31,050 8.9 7,580 6,520 25,865 7.4
-17.8 C (0 F) 5,300 4,555 18,075 6.1 4,415 3,795 15,060 5.1
-28.9 C (-20 F) 3,470 2,980 11,830 5.0 2,890 2,480 9,855 4.2
CSR-40SL Models with Three Evaporator Fans — Air Cooled Condensing*
*System net cooling capacity with a 37.8 C (100 F) ambient air temperature and R-404A.
System Net Cooling Capacity — Full Cool
Return air to 460/230V, 3 Phase, 60 Hz Power 380/190V, 3 Phase, 50 Hz Power
evaporator Net Cooling Capacity Power Consp Net Cooling Capacity Power Consp
coil inlet Watts Kcal/hr BTU/hr kW @460V Watts Kcal/hr BTU/hr kW @380V
21.1 C (70 F) 12,510 10,760 42,695 10.3 10,420 8,960 35,565 8.6
1.7 C (35 F) 8,010 6,890 27,340 8.5 6,675 5,740 22,775 7.1
-17.8 C (0 F) 4,435 3,815 15,135 5.2 3,695 3,180 12,610 4.3
-28.9 C (-20 F) 2,810 2,415 9,590 4.6 2,340 2,015 7,990 3.8
CSR-20SL Models with Three Evaporator Fans — Air Cooled Condensing*
*System net cooling capacity with a 37.8 C (100 F) ambient air temperature and R-404A.
