Thermo King Spectrum User Manual

46
TK 61651-18-OP-EN
Specifications
Refrigeration System
Contact your Thermo King dealer for refrigeration system service or
maintenance.
Compressor
V-100/
V-200s
V-200 V-300 V-500/
V-600
V-800
Compressor Model QP08N QP13 QP15 QP16 QP21
Displacement (cc) 82 131 146.7 163 215
Number of cylinders
6 6 6 6 10
Electrical Control System
12 Vdc 24 Vdc
Fuses
Common Fuses
Fuse 3: Evaporator Fan Motor (EFM1) 15 amps 10 amps
Fuse 4: Evaporator Fan Motor (EFM2) 15 amps 10 amps
Fuse 5: Roadside (Engine) Compressor Clutch
(CCL1), Liquid Injection Switch (LIS), Liquid
Injection Valve (LIV), EVAP1 Defrost Hot Gas
Solenoid Valve (PS1), Compressor Motor Contactor
(CMC), Heat Pilot Solenoid (PS5)
20 amps 10 amps
Fuse 14: Vehicle Ignition Switch 5 amps 5 amps
Fuse 30: Condenser Fan Motor (CFM) (located in
CF1 wire near terminal strip in condenser section)
16 amps 10 amps
V-100/V-200s
Fuse 6: Condenser Fan 1/2 2 amps 2 amps
Fuse 21: Battery Power Supply (located in 2 wire
near battery)
30 amps 30 amps
