TOOL KIT AND SPARE PARTS
ENOM00109-0
The followings are a list of the tools and spare parts provided with the motor.
Items Quantity Remark
Tool b ag
1Socket wrench 16
1Socket wrench 10-13
1Socket wrench handle
1Pliers
1± Screwdriver
Emergency starter rope 1
Spark plug 1 NGK DCPR6E
Propeller nut split pin 1 In tool bag
Owner’s manual 1
Spare stop switch lock 1
Rigging bolt set
2Bolt M8 X 85mm
Manual tilt model4Washer M8
2Nylon locking nut M8
4Bolt M12 P1.25 X 105mm
Power tilt model
4Washer 13-34-3
4Washer M12
4Nylon locking nut M12P1.25
Cable joint set
2Cable joint
E and ET model2Washer 8.5-18-1.6
2Snap pin
Items: Remote control fitting assy
1Drag link assy
ET model
1Steering hook plate
2Bolt M10
2Washer M10
