PRE-OPERATING PREPARATIONS 35
6
ENOM00039-1
If outboard motor encounters an abnor-
mal condition of fault, the warning buzzer
will emit a continuous beep or intermit-
tent short beeps. The warning lamp (LED)
will synchronize with the buzzer and
engine speed will be limited (engine will
not stop).
See next page for conditions which will
lead to an abnormal condition or fault.
ENOM00040-A
Location of warning buzzer and
lamp
Warning buzzer
RC model: Located inside the remote
control.
Multi-Function tiller handle model:
Located in the tiller handle.
Tiller handle model: Located in the
engine cover.
Warning lamp (LED)
RC model: Located in the tachometer &
bottom cowl.
Multi-Function tiller handle & Tiller han-
dle models: Located on the bottom cowl.
ENON00009-A
Note
Warning lamp for optional tachometer will
synchronize with the warning lamp on
engine side
1. Warning lamp
1. Warning lamp
5. Warning system
To Next Page
