5
TECHNICAL DESCRIPTION U/M TS120-S45-U
Cleaning width mm/in 500/20
Squeegee width mm/in 770/30
Working capacity sqm/h/sqft/h 2000/21,528
Brush diameter mm/in 500/20
Brush rpm rpm 155
Pressure on the brush kg/lbs 20/44 max
Brush motor W/A 350/14.6
Type of drive semi-automatic
Maximum gradient % 2
Suction motor W/A 450/18.8
Suction vacuum mbar\in water
lift
120/48
Solution tank l/gal 40/11
Recovery tank l/gal 45/12
Machine length mm/in 1195/47
Machine height mm/in 1053/42
Machine width (without squeegee) mm/in 530/21
Weight of the batteries kg/lbs 74/163
Compartment of the batteries mm/in 342x340x295 /13.5x13.4x11.6
Weight of the machine (empty and without
batteries)
kg/lbs 66/146
Acoustic pressure level (in conformity with
IEC 704/1)
dB(A) <70
Class III
Protection level IP X3
Tension V 24
“RECOMMENDED BRUSHES".
− Do not take off the
protections which require the
use of tools for their removal.
− Do not wash the machine
with direct water, jets or with
high water pressure nor with
corrosive material.
− Every 200 working hours
have a machine check by an
authorized service department.
− Before using the machine,
check that all panels and
coverings are in their position
as indicated in this use and
maintenance catalogue.
