Tornado BD 20/11L User Manual

6
INSTRUMENT BOARD AND CONTROLS
1. SIGNAL LAMP CHARGE LEVEL BATTERIES
2. SWITCH BRUSH MOTOR
3. SWITCH SUCTION MOTOR
4. SIGNAL LAMP SOLUTION VALVE OPEN
MACHINE
1. BRUSH BASE GROUP
2. PLUG EXHAUST HOSE RECOVERY TANK
3. RECOVERY TANK
4. INSTRUMENT BOARD
5. LEVERS MOVEMENT
6. SCREW CAP FOR INLET DETERGENT
SOLUTION
7. GUIDE SPRING SQUEEGEE HOSE
5. LEVERS MOVEMENT
6. LEVER SOLUTION VALVE
7. LEVER SQUEEGEE LIFTING
8. PEDAL BRUSH BASE GROUP LIFTING
8. SQUEEGEE HOSE
9. BATTERIES
10. INLET OPENING SQUEEGEE HOSE
11. SUCTION COVER
12. SOLUTION TANK
13. WHEELS
14. SQUEEGEE ASSEMBLY
15. CASTOR WHEELS
