Toro 07253 User Manual

20
1
2
Figure 14
1. Choke 2. Gear shift selector
Gear Shift Selector
The gear shift selector moves the vehicle in the desired
direction—forward or reverse (Fig. 14). The vehicle will
start in either direction.
Note: If the gear shift selector is in Reverse when the
ignition is turned on, a buzzer will sound to warn the
operator.
Important The vehicle should always be stopped
before changing the gear selection and direction.
Ignition Switch
The ignition switch (Fig. 15), used to start and stop the
engine, has two positions: Off and On. Rotate the key
clockwise to the On position to allow operation. When the
vehicle is stopped, rotate the key counterclockwise to the
Off position. Remove the key from the ignition.
Hour Meter
The hour meter (Fig. 15) indicates the total number of
hours the engine is running. The hour meter starts to
function whenever the accelerator is depressed.
Oil Light
The oil light warns the operator if the engine oil pressure
drops below a safe level (Fig. 15). If the light comes on and
remains lit, the oil level should be checked and oil added if
necessary; see Engine Oil, page 27.
Note: The oil light may flicker. This is normal and no
action needs to be taken.
Light Switch
Toggle the switch to activate the headlights. Push it to turn
the lights on (Fig. 15).
Power Point
The power point is used to power optional electrical
accessories (Fig. 15).
12
3
4
5 m–4885
Figure 15
1. Ignition switch
2. Hour meter
3. Light switch
4. Oil light
5. Power Point
Fuel Gauge
The fuel gauge (Fig. 16) shows the amount of fuel in the
tank.
1
Figure 16
1. Fuel gauge
