Toro 07433LT User Manual

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Steeringwheel
1
Steeringwheelcover
1
Washer(1/2inch)
1
1
Dustcover1
Installthesteeringwheel(International
modelsonly).
2
Nopartsrequired
–
Checktheuidlevelsandtirepressure.
3
Nopartsrequired
–
Burnish(break-in)thebrakes.
Operator'sManual
1
Engineowner'smanual1
Registrationcard1
PredeliveryInspectionForm1
CerticateofQuality
1
4
Key2
ReadtheOperator'sManualandview
thesetupmaterialbeforeoperatingthe
machine.
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
1
InstallingtheSteering
Wheel(InternationalModels
Only)
Partsneededforthisprocedure:
1
Steeringwheel
1
Steeringwheelcover
1
Washer(1/2inch)
1Dustcover
Procedure
1.Ifthecoverisinstalled,removeitfromthehub
ofthesteeringwheel(Figure3).
2.Removethelocknut(1/2inch)fromthesteering
shaft(Figure3).
3.Slidethesteeringwheel,dustcover,andwasher
(1/2inch)ontothesteeringshaft(Figure3).
Note:Withthefrontwheelsstraight,orientthe
steeringwheelsothatthesmallerspokeonthe
steeringwheelisvertical.
4.Securethesteeringwheeltotheshaftwiththe
locknut(1/2inch)andtightenitto18to30N∙m
(13to22ft-lb).
5.Installthecoveronthesteeringwheel(Figure3).
g198932
Figure3
1.Steeringwheelcover4.Steeringwheel
2.Locknut(1/2inch)
5.Dustcover
3.Washer(1/2inch)6.Steeringshaft
10
