GreasingtheFrontWheel
Bearings
ServiceInterval:Every300hours
Greasespecication:MobilgreaseXHP™-222
RemovingtheHubandRotor
1.Liftthefrontofthemachineandsupportitwith
jackstands.
2.Removethe4lugnutsthatsecurethewheel
tothehub(Figure31).
g033046
Figure31
1.Hub3.Lugnut
2.Wheel
3.Removetheange-headbolts(3/8x3/4inch)
thatsecurethebracketforthebrakeassembly
tothespindleandseparatethebrakefromthe
spindle(Figure32).
Note:Supportthebrakeassemblybefore
proceedingtothenextstep.
g033047
Figure32
1.Flange-headbolts(3/8x
3/4inch)
3.Caliperbracket(brake
assembly)
2.Spindle
4.Removethedustcapfromthehub(Figure33).
g192346
Figure33
1.Cotterpin4.Spindlenut
2.Spindle
5.Nutretainer
3.Tabwasher6.Dustcap
5.Removethecotterpinandnutretainerfromthe
spindleandspindlenut(Figure33).
6.Removethespindlenutfromthespindle,and
separatethehubandrotorassemblyfromthe
spindle(Figure33andFigure34).
35
