AdjustingtheNeutral
Gear-ShiftPosition
1.Loosenthejamnutsonthegear-shiftcableand
adjustthemasnecessary(Figure61).
g034455
Figure61
1.Shiftlever3.Gear-shiftcable
2.Spannerbar
4.Jamnuts
2.T estthegear-shiftpositionbyrotatingthe
gear-shiftselectortothe3differentpositions
andchecktoseeiftheshiftlever(Figure61)
shiftsproperlywhenshiftingthegears;referto
Gear-ShiftLeverandGear-ShiftIndicator(page
14).
3.Verifythatallofthepositionsareworking
correctlybyrepeatingthestepsinCheckingthe
NeutralGear-ShiftPosition(page51).
MaintainingthePrimary
DriveClutch
ServiceInterval:Every400hours/Yearly(whichever
comesrst)
CAUTION
Thedustintheclutchwillbecomeairborne
andcoulddamageyoureyesoryoucould
inhaleit,causingbreathingdifculties.
Wearsafetygogglesandadustmaskor
othereyeandrespiratoryprotectionwhen
performingthisprocedure.
1.Raiseandlatchthecargobed.
2.Removethe3boltssecuringthecovertothe
clutch,andremovethecover(Figure62).
Note:Retainthecoverandboltsforinstallation.
g011947
Figure62
1.Cover
2.Bolts
3.Thoroughlycleantheinsideofthecoverand
theinnercomponentsoftheclutchusing
compressedair.
4.Installtheclutchcoverandsecureitwiththe3
bolts(Figure62)thatyouremovedin2.
5.Lowerthecargobed.
ReducingtheTopSpeed
CAUTION
Thedustintheclutchwillbecomeairborne
andcoulddamageyoureyesoryoucould
inhaleit,causingbreathingdifculties.
Wearsafetygogglesandadustmaskor
othereyeandrespiratoryprotectionwhen
performingthisprocedure.
1.Raiseandlatchthecargobed;refertoRaising
theCargoBedtotheServicePosition(page22).
2.Removetheboltssecuringtheprimaryclutch
coverasshowninFigure63.
Important:Usecautionwhenremoving
theclutchcover;thespringisunder
compression.
Important:TakenoteoftheXorientation
ontheclutchcoversandclutchassemblies
forlaterinstallation.
