13
Measurements
Width of cut 109 in. (2.8 m)
Overall width
cutting units down
cutting units up (transport)
112.8 in. (286 cm)
88.25 in. (224 cm)
Overall length 145.8 in. (370 cm)
Height with ROPS 85 in. (216 cm)
Ground clearance 6 in. (15 cm)
Track Width
front
rear
88.25 in. (224 cm)
55.5 in. (141 cm)
Wheel base 67-1/2 in. (171 cm)
Weight (with cutting units and
no fluids)
4123 lb. (1400 kg)
Optional Equipment
27” Rotary Cutting Unit Model No. 30827
Deluxe Seat Kit (Seat suspension
not included)
Model No. 30398
Seat Suspension Kit Model No. 30395
Arm Rest Kit Model No. 30707
Mulching Baffle Kit
(one per cutting unit)
Model No. 30828
High Lift Parallel Sail Blade
(one per cutting unit)
Part No. 105–4089
Do not use the high lift blade with the mulching
baffle. The blade could break, resulting in personal
injury or death.
Warning
