15
Before Operating
If you leave the key in the ignition switch, someone
could accidently start the engine and seriously
injure you or other bystanders.
Remove the key from the ignition before you do
any maintenance.
Caution
Checking the Engine Oil
Check the oil level at the beginning of each day.
The crankcase capacity is 8 qt. (7.6 l) with the filter.
1. Park the machine on a level surface. Unlock the engine
cover latches.
2. Open the engine cover.
3. Remove the dipstick, wipe it clean, install the dipstick
into the tube, and pull it out again. The oil level should
be up to the FULL mark (Fig. 1).
1
Figure 1
1. Dipstick
4. If the oil is below the FULL mark, remove the fill cap
(Fig. 2) and add oil until the level reaches the FULL
mark. Do not overfill.
1
Figure 2
1. Oil fill cap
5. The engine uses any high-quality detergent oil having
the American Petroleum Institute (API) “service
classification” CD, CE, CF, CF-4, or CG-4. Use the
following chart to select the proper viscosity grade for
the temperature expected.
above 77°F (25°C)
SAE 30
10W-30
or
10W-40
32° to 77°F (0° to 25°C)
SAE 20
10W-30
or
10W-40
below 32°F (0°C)
SAE 10
10W-30
or
10W-40
Note: When using different oil, drain all old oil from the
crankcase before adding new oil.
6. Install the oil fill cap and dipstick.
7. Close the engine cover and secure it with the latches.
Checking the Cooling System
Check level of coolant at the beginning of each day.
Capacity of system is 2-3/4 gal. (10.4 l).
1. Carefully remove the radiator cap and expansion tank
cap (Fig. 3).
