CheckingtheSkidsand
Scraper
NoPartsRequired
Procedure
RefertoCheckingandAdjustingtheSkidsandScraper
inMaintenance.
9
CheckingtheTractionDrive
Operation
NoPartsRequired
Procedure
CAUTION
Ifthetractiondriveisnotproperlyadjusted,the
machinemaymoveinthedirectionoppositeof
whatyouintended,causinginjuryand/orproperty
damage.
Carefullycheckthetractiondriveandadjustit
properly,ifnecessary.
1.Starttheengine;refertoStartingtheEngine.
2.MovethespeedselectortoPositionR1;referto
OperatingtheSpeedSelector.
3.Squeezethelefthand(traction)levertothehand-grip
(
Figure20).
Figure20
Themachineshouldmoverearward.Ifthemachine
doesnotmoveormovesforward,completethe
following:
A.Releasethetractionleverandstoptheengine.
B.Disconnectthetrunnionfromthespeedselector
lever(
Figure11).
C.Turnthetrunniondownward(clockwise)onthe
speedcontrolrod(Figure11).
D.Connectthetrunniontothespeedselectorlever
(
Figure11).
4.Releasethetractionlever.
5.MovethespeedselectortothePosition1;referto
OperatingtheSpeedSelector.
6.Squeezethelefthand(traction)levertothehand-grip
(
Figure20).
Themachineshouldmoveforward.Ifthemachine
doesnotmoveormovesrearward,completethe
following:
A.Releasethetractionleverandstoptheengine.
B.Disconnectthetrunnionfromthespeedselector
lever(
Figure11).
C.Turnthetrunnionupward(counterclockwise)on
thespeedcontrolrod(Figure11).
D.Connectthetrunniontothespeedselectorlever
(Figure11).
7.Ifyoumadeanyadjustments,repeatthisprocedure
untilnoadjustmentsarerequired.
Important:Ifthemachinemoveswhenthetraction
leverisinthereleasedposition,checkthetraction
cable(refertoCheckingandAdjustingtheTraction
Cable)ortakethemachinetoanAuthorizedService
Dealerforservice.
