1
InstallingtheUpperHandle
Partsneededforthisprocedure:
4Handlebolts
4
Curvedwashers
4Locknuts
Procedure
Note:Donotremovetherubberbandonthecables
untilyouhaveinstalledtheupperhandle.
1.Liftandrotatetheupperhandleandpositionitover
thelowerhandle(Figure3).
Important:Routethecablesattachedtothe
QuickStickinsidetheupperhandlelegsand
ensurethatthecablesandthewireforthe
headlightarenotpinchedbetweenthehandle
sections.
Figure3
1.Cables
2.Securetheupperhandlewith4handlebolts,
4curvedwashers,and4locknutsfromtheloose
partsbag(Figure4).
Figure4
2
InstallingtheWheelClutch
CableEnds
NoPartsRequired
Procedure
Models38624W,38634,38644,and38654only
1.Unwrapthecableendsfromthelowerhandle
(
Figure5).
Figure5
2.Routeeithertheleftorrightcableendoverthelower
handleandinsertthecableendintotheholeinthe
correspondingwheelclutchlever(Figure6).
8
