1.Removethedipstick,wipeitclean,thenfullyinstall
thedipstick.
2.Removethedipstickandchecktheoillevel
(
Figure41).IftheoillevelisbelowtheAddmark
onthedipstick,addoil.RefertoFillingtheEngine
withOil.
Figure41
CheckingandAdjustingthe
SkidsandScraper
ServiceInterval:Yearly—Checktheskidsandthe
scraperandadjustthemifnecessary
(allmodelsexceptmodel38654).
AllmodelsexceptModel38654
Checktheskidsandthescrapertoensurethattheauger
doesnotcontactthepavedorgravelsurface.Adjustthe
skidsandthescraperasneededtocompensateforwear.
1.Checkthetirepressure.RefertoCheckingtheTire
Pressure.
2.Loosenthenutsthatsecurebothskidstothe
augersidesuntiltheskidsslideupanddowneasily
(
Figure42).
Figure42
1.1/2inch(1.3cm)
3.Supportthesideplatessothattheyareatleast1/2
inch(1.3cm)abovealevelsurface.
Important:Theaugerbladesmustbe
supportedabovethegroundbytheskids.
4.Ensurethatthescraperis1/8inch(3mm)above
andparalleltoalevelsurface.
Note:Ifthepavementiscracked,rough,oruneven,
adjusttheskidstoraisethescraper.Forgravel
surfaces,adjusttheskidsfurtherdowntoprevent
themachinefrompickinguprocks.
5.Movetheskidsdownuntiltheyareevenwiththe
ground.
6.Firmlytightenthenutsthatsecurebothskidstothe
augersides.
Note:Toquicklyadjusttheskidsiftheyloosen,
supportthescraper1/8inch(3mm)offthe
pavement,thenadjusttheskidsdowntothe
pavement.
Note:Iftheskidsbecomeexcessivelyworn,you
canturnthemoverandsettheunusedsidetoward
thepavement.
CheckingandAdjustingthe
Skids
ServiceInterval:Yearly—Checktheskidsandadjust
themifnecessary(model38654only).
Model38654only
Checktheskidstoensurethattheaugerdoesnot
contactthepavedorgravelsurface.Adjusttheskidsas
neededtocompensateforwear.
1.Checkthetirepressure.RefertoCheckingtheTire
Pressure.
2.Movethemachinetoalevelsurface.
3.Loosenthenutsthatsecurebothskidstothe
augersidesuntiltheskidsslideupanddowneasily
(
Figure43).
Figure43
1.Skid
4.Pushdownonthehandlestoallowthepivoting
scrapertomovefullyforward,thensetthefront
21
