OperatingtheSpeedSelector
Thespeedselectorhas6forwardand2reversegears.
Tochangespeeds,releasethetractionleverandshiftthe
speedselectorlevertothedesiredposition(Figure36).
Theleverlocksinanotchateachspeedselection.
Figure36
OperatingtheAuger/Impeller
Drive
1.Toengagetheauger/impellerdrive,squeezethe
righthand(auger/impeller)levertothehandgrip
(Figure37).
Figure37
2.Tostoptheaugerandimpeller,releasetheright
handlever.
Important:Whenyouengageboththe
auger/impellerleverandthetractionlever,the
tractionleverlockstheauger/impellerlever
down,freeingyourrighthand.Toreleaseboth
levers,simplyreleasethelefthand(traction)
lever.
3.Iftheaugerandimpellercontinuetorotatewhen
youreleasetheauger/impellerlever,donotoperate
themachine.Checktheauger/impellercable(refer
toCheckingandAdjustingtheAuger/Impeller
Cable)andadjustitifnecessary.Otherwise,takethe
machinetoanAuthorizedDealerforservice.
WARNING
Iftheaugerandimpellercontinuetorotate
whenyoureleasetheauger/impellerlever,you
couldseriouslyinjureyourselforothers.
Donotoperatethemachine.Takeittoan
AuthorizedServiceDealerforservice.
OperatingtheQuickStick™
HoldthebluetriggercapdowntousetheQuickStick
tomovethedischargechuteandthechutedeector.
Releasethetriggercaptolockthedischargechuteand
chutedeectorintoposition(
Figure38).
Figure38
MovingtheDischargeChute
HoldthebluetriggercapdownandmovetheQuick
Sticktothelefttomovethedischargechutetotheleft;
movetheQuickSticktotherighttomovethedischarge
chutetotheright(Figure39).
Figure39
18
