InstallingtheAuxiliaryHandle
Partsneededforthisprocedure:
1.Positiontheauxiliaryhandleontheshaftofthetrimmerwiththe
smoothsurfacefacingtheoperator(
Figure2).
G017277
Figure2
1.Auxiliaryhandle3.Brace
2.Latch
2.Slidethebraceintotheauxiliaryhandlesothatthebracerestsin
thegroovealongtheshaft(Figure2).
3.Slidethelatchfromtheleftthroughthehandleandbraceas
shownandtightenthelatchscrewwithaPhillipsheadscrewdriver
(Figure2).
3
InstallingtheGuard
Partsneededforthisprocedure:
1.SlidetheguardontothetrimmerbaseasshowninFigure3.
G017622
Figure3
1.Phillipsheadscrew
2.Guard
2.SecuretheguardusingaPhillipsheadscrew.
