ProductOverview
G019730
1
2
3
4
5
6
7
8
Figure10
Side-DumpModels
1.Enginecowl5.Towpole
2.Engineswitch
6.Safety-chainkeyholes
3.Drum7.Drum-tiltbrake
4.Handwheel8.Rubberlatch
5
4
3
2
1
6
7
8
G019914
9
10
11
12
11
Figure11
End-DumpModels
1.Tongue-mountedtow
coupler
7.Handwheel
2.Safety-chainkeyholes
8.Drum-tiltbrake
3.Rubberlatch9.Frontstabilizerleg
4.Engineswitch10.Rearwardpinhole
5.Enginecowl
11.Clevispin
6.Drum12.Rearstabilizerlegs
