g017848
Figure71
1.Leftcableadjustment
3.Rightcableadjustment
2.Cablelock
HydraulicSystem
Maintenance
ServicingtheHydraulic
System
HydraulicOilType:Toro
®
HYPR-OIL
™
500
hydraulicoilorMobil
®
115W-50syntheticmotoroil.
HydraulicSystemOilCapacity:67oz.(2.0l)
Important:Useoilspecied.Otheruidscould
causesystemdamage.
CheckingtheHydraulicFluid
ServiceInterval:Aftertherst8hours
Every50hours
Note:Therearetwowaysofcheckingthehydraulicoil.
Oneiswhentheoiliswarmandoneiswhentheoilis
cold.Thebafeinsidethetankhastwolevelsdepending
iftheoiliswarmorcold.
1.Positionmachineonalevelsurface.
2.Disengagethepowertakeoff(PTO)andshutoff
theengine.
3.Waitforallmovingpartstostopbeforeleavingthe
operatingpositionandthensettheparkingbrake.
4.Cleanareaaroundcapandllerneckofhydraulic
tank(
Figure72).
G012005
4 1 3
2
Figure72
1.Cap3.Colduidlevel-full
2.Bafe4.Hotuidlevel-full
5.Removecapfromllerneck.Lookinsidetocheck
theuidlevelinthereservoir.(
Figure72).
6.Adduidtothereservoiruntilitreachesthecold
levelofthebafe.
50
