ElectricalSystem
Maintenance
ElectricalSystemSafety
•Disconnectthebatterybeforerepairingthe
machine.Disconnectthenegativeterminalrst
andthepositivelast.Connectthepositiveterminal
rstandthenegativelast.
•Chargethebatteryinanopen,well-ventilated
area,awayfromsparksandames.Unplugthe
chargerbeforeconnectingordisconnectingthe
battery.Wearprotectiveclothinganduseinsulated
tools.
WARNING
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandlead
compounds,chemicalsknownto
theStateofCaliforniatocause
cancerandreproductiveharm.Wash
handsafterhandling.
ServicingtheBattery
ServiceInterval:Every25hours—Checkthe
electrolytelevel.(Ifthemachineis
instorage,checkitevery30days.)
Important:Beforeweldingonthemachine,
disconnectthenegativecablefromthebatteryto
preventdamagetotheelectricalsystem.
Note:Checkthebatteryconditionweeklyorafter
every50hoursofoperation.Keeptheterminalsand
theentirebatterycasecleanbecauseadirtybattery
willdischargeslowly.Tocleanthebattery,washthe
entirecasewithasolutionofbakingsodaandwater.
Rinsewithclearwater.Coatthebatterypostsand
cableconnectorswithGrafo112X(skin-over)grease
(ToroPartNo.505-47)orpetroleumjellytoprevent
corrosion.
1.Openthebatterycoveronthesideoftheshroud
(Figure85).
Note:Pressdownontheatsurfaceabovethe
batterycovertoeasetheremovalofthecover
(Figure85).
2
g020758
g020758
Figure85
1.Batterycover2.Pressdownhere.
g020451
Figure86
1.Battery
WARNING
Chargingthebatteryproducesgasses
thatcanexplode.
Neversmokenearthebatteryandkeep
sparksandamesawayfrombattery.
2.Removetherubberbootfromthepositive
terminalandinspectthebattery.
64
