Operation
18
Parking Brake
Always set the parking brake when you stop the
machine or leave it unattended.
Setting the Parking Brake
1. Pull the upper control bar rearward and hold it in
this position (Fig. 13).
2. Lift the parking brake lock up and gradually
release the upper control bar (Fig. 13). The brake
lock should stay in the set (locked) position.
Releasing the Parking Brake
1. Pull rearward on the upper control bar (Fig. 13).
Lower the parking brake lock to the released
position.
2. Gradually release the upper control bar.
1
2
m–4212
Figure 13
1. Upper
control bar
2.
Parking brake lock
