Maintenance
31
m–4396
Figure 25
m–4056
Figure 26
4. Pump grease into the fittings until grease begins
to ooze out of the bearings (approximately 3
pumps).
5. Wipe up any excess grease.
Changing
the Fuel Filter
Change the fuel filter after every 200 operating hours
or yearly, whichever occurs first.
Never re-install a dirty filter.
1. Lower the loader arms and stop the engine.
Remove the key.
2. Shut off the fuel valve on the bottom of each fuel
tank (Fig. 28).
3. Clamp the fuel line between the fuel tanks and
the fuel filter to block the fuel flow.
4. Squeeze the ends of the hose clamps together
and slide them away from the filter (Fig. 27).
5. Place a drain pan under the fuel lines to catch
any leaks, then remove the filter from the fuel
lines.
6. Install a new filter and move the hose clamps
close to the filter.
7. Remove the clamp blocking fuel flow and open
the fuel valves.
