Toro Titan ZX4800 User Manual

Controls
Becomefamiliarwithallthecontrolsbeforeyoustart
theengineandoperatethemachine(Figure5).
g017722
Figure5
1.Throttlecontrol4.Ignitionswitch
2.Choke5.Bladecontrolswitch(PTO)
3.Hourmeter
IgnitionSwitch
Theignitionswitchhasthreepositions:Start,Run
andOff.ThekeywillturntoStartandmovebackto
Runuponrelease.TurningthekeytotheOffposition
willstoptheengine;however,alwaysremovethekey
whenleavingthemachinetopreventtheenginefrom
accidentallystarting(Figure5).
ThrottleControl
ThethrottlecontrolisvariablebetweenFastand
Slow.Movingthrottleleverforwardwillincrease
enginespeedandmovingthrottlelevertotherearwill
decreaseenginespeed.Movingthethrottleforward
intothedetentisfullthrottle(Figure5).
Choke
Usethechoketostartacoldengine.Pullthechoke
knobuptoengageit.Pushdownonthechokeknob
todisengageit.
Blade-ControlSwitch(Power
Take-Off)
Thebladecontrolswitchengagesanddisengages
powertothemowerblades(Figure5).
HourMeter
Thehourmeterrecordsthenumberofhoursthe
bladeshaveoperated.Itoperateswhentheblade
controlswitch(PTO)isengaged.Usethesetimesfor
schedulingregularmaintenance(Figure5).
FuelGauge
Thefuelwindowlocatedbelowtheoperatorposition
canbeusedtoverifythelevelofgasolineinthetank
(Figure6).
MotionControlLevers
Themotioncontrolleversarespeedsensitivecontrols
ofindependentwheelmotors.Movingaleverforward
orbackwardturnsthewheelonthesamesideforward
orinreverse;wheelspeedisproportionaltothe
amounttheleverismoved.Movethecontrollevers
outwardfromthecentertotheneutrallockposition
andexitthemachine(Figure4).Alwayspositionthe
motioncontrolleversintotheneutrallockposition
whenyoustopthemachineorleaveitunattended.
ParkingBrakeLever
Theparkingbrakeleverislocatedonleftsideof
theconsole(Figure4).Thebrakeleverengagesa
parkingbrakeonthedrivewheels.Pulltheleverup
andrearwardtoengagethebrake.Pushthelever
forwardanddowntodisengagethebrake.
FootPedalDeckLiftSystem
Thefootpedaldeckliftsystemallowstheoperator
tolowerandraisethedeckfromtheseatedposition.
Theoperatorcanusethefootpedaltoliftthedeck
brieytoavoidobstaclesorlockthedeckinthe
highestheight-of-cutortransportposition(Figure4).
Height-of-CutLever
Theheight-of-cutleverworkswiththefootpedalto
lockthedeckinaspeciccuttingheight.Onlyadjust
theheightofcutwhilemachineisnotmoving(Figure
4).
Attachments/Accessories
AselectionofT oroapprovedattachmentsand
accessoriesisavailableforusewiththemachineto
enhanceandexpanditscapabilities.Contactyour
AuthorizedServiceDealerorDistributororgoto
www.T oro.comforalistofallapprovedattachments
andaccessories.
14

Toro Titan ZX4800 Specifications

General

Transmission	Hydrostatic
Cutting Width	48 inches
Ground Speed (Reverse)	4 mph
Seat	High-back, adjustable
Tires (Rear)	20 x 10.0-8
