Toro Titan ZX4800 User Manual

g024410
Figure23
1.Deckliftpedal3.Height-of-cutpositions
2.Handle4.Pin
AdjustingtheAnti-Scalp
Rollers
Wheneveryouchangetheheight-of-cut,itis
recommendedtoadjusttheheightoftheanti-scalp
rollers.
1.Disengagethebladecontrolswitch(PTO),move
themotioncontrolleverstotheneutrallock
positionandsettheparkingbrake.
2.Stoptheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Removetheangenut,anti-scalprollerandbolt
fromthebracket(Figure24).
Note:Keeptheboltandanti-scalproller
togetherwhenremoving.
g024312
Figure24
1.FlangeNut4.Bushing
2.Spacer
5.Bolt
3.Anti-scalproller
4.Aligntheboltandanti-scalprollerintheholeof
thebracketthatmatchedtheclosestheightof
cutposition(Figure24).
5.Inserttheboltintothebracketholeandsecure
theboltandanti-scalprollerwiththeangenut
(Figure24).
24

Toro Titan ZX4800 Specifications

General

Transmission	Hydrostatic
Cutting Width	48 inches
Ground Speed (Reverse)	4 mph
Seat	High-back, adjustable
Tires (Rear)	20 x 10.0-8
