Toro Titan ZX4800 User Manual

g020312
Figure66
1.Springremovaltool(T oro
partno.92-5771)
4.Idlerarm
2.Idlerspring5.Mowerbelt
3.Deckpost
7.Lowerthemowertothelowestheight-of-cut.
8.Placetheheight-of-cutpininthelockposition
forlowestheight-of-cut.
9.Removethebeltfromthemowerdeckpulleys
andremovetheexistingbelt.
InstallingtheBelt
1.Installthenewbeltaroundthemowerpulleys
andtheclutchpulleyundertheengine(Figure
66).
2.Usingaspringremovaltool(Toropartno.
92-5771),installtheidlerspringoverthedeck
postandplacetensionontheidlerpulleyand
mowerbelt(Figure66).
3.Ensurethatthebeltisproperlyseatedinall
pulleys.
4.Installthebeltcovers(Figure67).
g020313
Figure67
1.Positionthebeltcoverand
ensurethatthetabsseat.
3.Tightenthescrews
2.Pivotthebeltcoverdown
RemovingtheMower
Parkthemachineonalevelsurfaceanddisengage
thebladecontrolswitch.Movethemotioncontrol
leversoutwardtotheneutralposition,engageparking
brake,stoptheengine,removethekey,andwaitfor
allmovingpartstostopbeforeleavingtheoperating
position.
Lowerthemowertothelowestheight-of-cut.Select
oneofthefollowingproceduresdependingonthe
mowerdecksizeinstalledtocompletetheremoval.
PreparingtoRemovetheMower
Deck
1.Lowerthemowertothe76mm(3inch)
height-of-cutposition.
2.Removethemowerbeltfromtheenginepulley;
refertoRemovingtheBelt(page48).
49

Toro Titan ZX4800 Specifications

General

Transmission	Hydrostatic
Cutting Width	48 inches
Ground Speed (Reverse)	4 mph
Seat	High-back, adjustable
Tires (Rear)	20 x 10.0-8
