Toro TX 427 User Manual

Parking-BrakeLever
•Toengagetheparkingbrake,pushthelever
forwardandtotheleftandthenpullitrearward
(Figure13).
Note:Thetractionunitmayrollslightlybeforethe
brakesengageinthedrivesprocket.
•Toreleasethebrake,pushtheleverforwardand
thenright,intothenotch(Figure13).
g005552
Figure13
FuelGauge
Thisgaugemeasurestheamountoffuelinthefuel
tank(s).
Hydraulic-FluidTemperatureLight
Ifthehydraulicuidgetstoohot,thislightilluminates
andanaudiblealarmsounds.Ifthishappens,shutoff
theengineandallowthetractionunittocool.
Specications
Note:Specicationsanddesignaresubjectto
changewithoutnotice.
Model22321,22321G,22342HD
Width
86cm(34inches)
Length
180cm(71inches)
Height
117cm(46inches)
Weight
853kg(1,880lb)
Operatingcapacitywith
standardbucket
227kg(500lb)
Tippingcapacitywith
standardbucket
671kg(1,480lb)
Wheelbase
79cm(31inches)
Dumpheight(with
standardbucket)
119cm(47inches)
Reach—fullyraised(with
standardbucket)
55cm(22inches)
Heighttohingepin(with
standardbucketinhighest
position)
168cm(66inches)
Model22322
Width
104cm(41inches)
Length
180cm(71inches)
Height
117cm(46inches)
Weight
941kg(2,075lb)
Operatingcapacitywith
standardbucket
227kg(500lb)
Tippingcapacitywith
standardbucket
647kg(1,427lb)
Wheelbase
79cm(31inches)
Dumpheight(with
standardbucket)
119cm(47inches)
Reach—fullyraised(with
standardbucket)
55cm(22inches)
Heighttohingepin(with
standardbucketinhighest
position)
168cm(66inches)
Attachments/Accessories
AselectionofT oroapprovedattachmentsand
accessoriesisavailableforusewiththemachineto
enhanceandexpanditscapabilities.Contactyour
AuthorizedServiceDealerorDistributororgoto
www.T oro.comforalistofallapprovedattachments
andaccessories.
Important:UseonlyToroapprovedattachments.
Otherattachmentsmaycreateanunsafeoperating
environmentordamagethetractionunit.
Toensureoptimumperformanceandcontinuedsafety
certicationofthemachine,useonlygenuineToro
replacementpartsandaccessories.Replacement
partsandaccessoriesmadebyothermanufacturers
couldbedangerous,andsuchusecouldvoidthe
productwarranty.
12

Toro TX 427 Specifications

General

Engine Make	Kubota
Engine Model	D1105
Max Digging Depth	10 ft 6 in (3.2 m)
Digging Depth	10 ft 6 in (3.2 m)
Bucket Width	12 in
