ClosingtheHood
1.Lowerthehood,andholditdownwhileyou
securethelatches..
2.Tightenthehood-lockingscrew(Figure38).
3.Removethecylinderlocksandlowertheloader
arms.
OpeningtheRear-AccessCover
1.Removethefastener(Figure39).
g260061
Figure39
1.Fastener
2.Lifttherear-accesscoverupandsecurethe
proprodtoaccesstheinternalcomponents
(Figure39).
g267537
Figure40
1.Proprod
RemovingtheRearScreen
1.Opentherear-accesscover;refertoOpening
theRear-AccessCover(page31).
2.Loosenthe2boltssecuringthebottomofthe
screen(Figure41).
3.Loosenthe2knobsonthescreen(Figure41).
g260063
Figure41
1.Knob(2)2.Bolt(2)
4.Liftthescreenandremoveit(Figure41).
RemovingtheBottomPlate
1.Removethe2boltssecuringthebottomplate
(Figure42).
g263690
Figure42
1.Bottomplate2.Bolt
2.Removethebottomplate.
31
